18 XB | SPECIFICATIONS
Length
17' 10"
Beam
97"
Transom Height
20"
Max Horsepower
115 HP
Side Height
24"
Bottom Width
69"
Approximate Draft
11"
Aluminum - 5052 Marine Grade Alloy
0.100
Deadrise @ Transom
13°
Deadrise @ Entry
45°
Approximate Boat Weight
1,089 lbs
Fuel Capacity
23 Gallons*
Aft Livewell
28 Gallons
Port Side Rod Locker
8 ft Rods
Persons & Total Persons Weight
4/650 lbs
Max Weight Capacity
1275 lbs
Dual Aft Storage Boxes
Length on Trailer
22' 3"
*The usable fuel capacity will be affected by factors such as EPA-required fuel system components, temperature, and boat loading which may reduce the usable fuel capacity by 10%.

18 XB | PERFORMANCE
BY THE NUMBERS
Brand
Yamaha
Model
F70LA
Horsepower
70 hp
Time To Plane
6:47 Sec
0-20 MPH
7.03 Sec
Propeller
Talon SS
Diameter/Pitch
13-1/8 x 14
Induction
EFI/SOHC
Displacement
996 CC
Weight (Estimated)
253 lbs
Gear Ratio
2.33:1
