20 XB | SPECIFICATIONS
Length
20' 1"
Beam
97"
Transom Height
20"
Max Horsepower
200 HP
Side Height
24"
Bottom Width
69"
Approximate Draft
11"
Aluminum - 5052 Marine Grade Alloy
0.125
Deadrise @ Transom
13°
Deadrise @ Entry
45°
Approximate Boat Weight
1,594 lbs
Fuel Capacity
32 Gallons*
Divided Livewell
28 Gallons
Center Rod Box with Monster Tube
8' Rods
Port Rod Box
5 Rods (7.5 ft)
Persons and Total Persons Weight
4/750 lbs
Max Weight Capacity
1760 lbs
Aft Insulated Fiberglass Storage Boxes
50 Quarts Ea
Forward Insulated Cooler/Day Box
37 Quarts
Length on Trailer
25' 1"
*The usable fuel capacity will be affected by factors such as EPA-required fuel system components, temperature, and boat loading which may reduce the usable fuel capacity by 10%.

20 XB | PERFORMANCE
BY THE NUMBERS
Brand
Yamaha
Model
VF200LA
Horsepower
200 hp
Induction
EFI/VCT/DOHC
Displacement
4.2L
Weight (Estimated)
505 lbs
Gear Ratio
1.75:1
